Sick DT50-P2113 Laser Distance Sensor with 20m Range

At a glance • > DT50-P2113 > 1047314 HDDM™ technology provides the best reliability, safety to ambient light and price/performance ratio • Most compact sensor offering up to 20 m range directly on the object • Amazing repeatability up to 1 mm • Very fast measurement and output rate with 500 Hz • Analog output with 4 mA ... 20 mA and one switching output • Red laser light for precise alignment • Tough metal housing with LC display Your benefits • • The fast measurement frequency increases the production throughput • • Red light and an optional alignment bracket reduces installation time • Intuitive setup via display or remote teach reduces installation time and costs • • • Metal housing withstands harsh environments, saving replacement costs Improved production quality based on high precision and small black/white shift of the measurement Thanks to its compact housing size, the DT50 Hi offers precise measurement in applications with limited space Immune to any type of ambient light - allows for use in optically challenging environments Widest temperature range allows for outdoor use without additional coolingSupply voltage VsDC 10V... 30V1)

Ripple ≤5Vpp2)

Power consumption ≤2.1W3)
